Varying dimensions and different designs regarding the number of layers and convection sheets lead to a wide range of models, suitable for different requiremets.

Type 10

Vertical radiator TYPE 10Vertical radiator TYPE 10



Height Height 1800 2000 2200 2400 2600
Width Length 500 and 600
Hub spacing 446 and 546
Depth Depth 46

Gradation: All overall heights from 1800 mm in 200 m gradations

Connections  Connections: 4 x G 1/2 I.G.

Test positive pressure  Test positive pressure: 13 bar

Maximal positive operating pressure  Max. positive operating pressure: 10 bar

Maximal operating temperature  Max. operating temperature: 110 °C

Type 20 K

Vertical radiator TYPE 20 KVertical radiator TYPE 20 K



Height Height 1800 2000 2200 2400 2600
Width Length 500 and 600
Hub spacing 446 and 546
Depth Depth 80


Gradation: All overall heights from 1800 mm in 200 m gradations

Connections  Connections: 4 x G 1/2 I.G.

Test positive pressure  Test positive pressure: 13 bar

Maximal positive operating pressure  Max. positive operating pressure: 10 bar

Maximal operating temperature  Max. operating temperature: 110 °C

Technical information

Each VERTICAL RADIATOR is equipped with suspension brackets welded onto the rear side. The 20 K radiator model is also supplied with two side grills.

Location of suspended straps

Location of suspended straps



Dimension Y = Height/2 - 20 mm
Dimension Z = Height - 120 mm

Downloads

Here you can download all relevant data in different file formats.

PDF

DXF / DWG

SOFTWARE & TOOLS

Colours

Our VERTICAL RADIATORS are available in 71 different colours.
