Hygiene valve radiator

Proved suitability for the installation in rooms with particular hygienic requirements.

Heat-Output-Calculator Brochure Hygiene certificate

Overview of models

The radiators manufactured by VOGEL&NOOT meet numerous internationally recognised quality standards and the manufacturing processes at all of the production sites have been ISO certified. Furthermore, the quality and performance data of VOGEL&NOOT panel radiators are constantly reviewed and confirmed by accredited european institutions.

Quality as a sign of maximum safety

Varying dimensions and different designs regarding the number of layers lead to a wide range of models, suitable for different requiremets.

Type 10 V

single-layer
Height	300	400	500	600	900
Length	up to 1200		up to 2400	up to 2600	up to 1400
Depth	46

Steps: all overall length starting with 400 mm available in steps of 200 mm, additionally 520, 720, 920, 1120 and 1320 mm

Connections: 4 x internal thread G 1/2"; 2 x G3/4" external thread bottom right	Max. positive operating pressure: 10 bar
Test positive pressure: 13 bar	Max. operating temperature: 110 °C

Type 20 V

double-layer
Height	300	400	500	600	900
Length	up to 2400		up to 3000		up to 2000
Depth	80

Steps: all overall length starting with 400 mm available in steps of 200 mm, additionally 520, 720, 920, 1120 and 1320 mm

Connections: 4 x internal thread G 1/2"; 2 x G3/4" external thread bottom right	Max. positive operating pressure: 10 bar
Test positive pressure: 13 bar	Max. operating temperature: 110 °C

Type 30 V

three-layers
Height	300	400	500	600	900
Length	up to 3000	up to 2200			up to 2000
Depth	166

Steps: any overall length starting with 400 mm available in steps of 200 mm, additionally 520, 720, 920, 1120 and 1320 mm

Connections: 4 x internal thread G 1/2"; 2 x G3/4" external thread bottom right

Test positive pressure: 13 bar

Max. positive operating pressure: 10 bar

Max. operating temperature: 110 °C

Technical information

The HYGIENE VALVE RADIATOR with its welded valve unit is suitable for double-pipe as well as for single-pipe installations, using a onepipe manifold. Additionally to the connection possibility at the bottom, the sophisticated design also offers connectionpossibilities, known from compact radiators, such as single-sided or two-sided connections.

The radiator is delivered ready for double-pipe installation, with a factory-adjusted kv-setting, appropriate to the radiator output.

For district heating installations with a big difference between water supply and return temperature, a steplessly adjustable valve element is available on request.

Connection modes - double-pipe system

A) Single-sided connection
B) Connection both sides
C) Connection on top (Warning: Lower performance)
D) Single-sided connection

Flow	Vent plug
Return	Drain plug
Blank plug

kv-value chart

Of course it is also possible to change the pre-adjusted valve setting when the equipment is operating at pressure.

Adjustment tips for built-in valve

Setting instructions:
VOGEL&NOOT valve radiators arefactory-fitted for double-pipe installations. Each individual radiator is fitted with a pre-adjusted valve insert, appropriate to the radiator output. The preset kv-value is also marked in colour on the front surface.

Please note: Should customised adjustments be required, the pre-set kv-values can be altered as needed.

Radiators are delivered with protective caps. After removing the protective cap (pos. A) the following thermostat heads can be fitted directly to the builtin valve (pos. B): “RA 2000”, “RAW” by Danfoss, “VK” by Heimeier, “D” by Herz, “thera DA” by MNG and “UNI XD” by Oventrop.

Single-pipe operation - factory-adjusted built-in valve

In single-pipe operation, setting the built-in valve on N.

The radiator will be delivered with a protective cap. After removing the protective cap (item A) the following thermostat heads can be installed directly onto the built-in valve (item B): „RA 2000“ and „RAW“ by Danfoss, „VK“ by Heimeier, „theraDA“ by MNG, as well as „UNI XD“ by Oventrop.

Caution: During the installation take care that the return element (2) has been installed at the water return, and the supply element (1) at the water supply. Changing the built-in valve from the right- to the left-hand side can easily be done at any time.

Downloads

Here you can download all relevant data in different file formats.

PDF

DXF / DWG

DXF and DWG 2D-vector graphics [zip; 14 MB ]

SOFTWARE & TOOLS

Colours

Our HYGIENE VALVE RADIATORS are available in 71 different colours.

RAL COLOURS

RAL9016 Traffic White
RAL 9010 Pure White
RAL 9001 Cream White
RAL 250-2 Lemon Glow
RAL 1023 Traffic Yellow
RAL 1012 Lemon Yellow
RAL 1004 Golden Yellow
RAL 1027 Curry
RAL 6034 Pastel Turquoise
RAL 5014 Pastel TurquoisePigeon Blue
RAL 5009 Azure Blue
RAL 5015 Sky Blue
RAL 5017 Traffic Blue
RAL 5022 Night Blue
RAL 5002 Ultramarine Blue
RAL 5001 Green Blue
RAL 9005 Jet Black
RAL 7021 Black Grey
RAL 1033 Dahlia Yellow
RAL 2003 Pastel Orange
RAL 2004 Pure Orange
RAL 3000 Flame Red
RAL 3005 Wine Red
RAL 4002 Red Violet
RAL 4007 Purple Violet
RAL 4008 Signal Violet
RAL 290 70 20 Mauve Haze
RAL 290 40 45 Mystic Purple
RAL 4009 Pastel Violet
RAL 3015 Light Pink
RAL 3014 Antique Pink
RAL 6019 Pastel Green
RAL 120 80 60 Modern green
RAL 120 70 70 E-Green
RAL 150 60 60 Green Apple
RAL 6033 Mint Turquoise
RAL 6004 Blue Green
RAL 8017 Chocolate Brown
RAL 8019 Grey Brown
RAL 040 80 05 White Coffee
RAL 7035 Light Grey
RAL 7040 Window Grey
RAL 7001 Silver Grey
RAL 7037 Dusty Grey
RAL 7030 Stone Grey
RAL 7013 Brown Grey
RAL 7015 Slate Grey
RAL 7016 Anthracite Grey
RAL 7024 Graphite Grey
RAL 9006 White Aluminium
RAL 9007 Grey Aluminium

The colours shown here are not binding. Colour variations are possible due to print-technical reasons. Further colours available on request!

SANITARY COLOURS

S0075 Jasmine
S0091 Pergamon
S0094 Natura
S0087 Bahama Beige
S0084 Anemone
S0077 Magnolia
S0164 Banana
S0088 Manhatten

The colours shown here are not binding. Colour variations are possible due to print-technical reasons. Further colours available on request!

SPECIAL COLOURS

S0145 Creme White
S0142 White Textured
S0141 Black Textured
S0147 Anodic Brown
S0148 Anodic Black
S0149 Anodic Natura
S0201 Metal Alu
S0102 Metal Grey
S0146 Anodic Bronze
S0104 Metal Black
S0144 Brown Grey
S0143 Light Grey

The colours shown here are not binding. Colour variations are possible due to print-technical reasons. Further colours available on request!

CE Marking and Declaration of Performance (DoP)

The European Union Construction Products Regulation requires that building products, including the radiators and the convectors without an integrated heat source, must be CE-marked in accordance with relevant harmonized product standards EN 442 and the Declaration of Performance (DoP). The CE marking means that each product meets the manufacturing process requirements of the product according to the provisions of manufacture, testing and delivery. The regulation came into force on July 1st, 2013.

Rettig ICC products are CE-marked and the Declaration of Performance of Rettig ICC and its reference documents, Annexes D and Annexes M describing the detailed performance of the products, are available according to the Construction Products Regulation. See the current DoP of RICC attached and the linked document files.

PDF

DoP CE Marking and Declaration of Performance (DoP) [pdf; 66 kB ]
